Solar Panels in Series Wiring Diagram
Solar panels are wired in series when you connect the positive terminal of one panel to the negative terminal of another. When solar panels are wired in series, the voltage of the panels adds together, but the amperage remains the same.
Battery to Battery ( DC to DC ) Split Charging Wiring Diagram
Battery to Battery ( DC to DC ) Split Charging with Wiring Diagram Battery-To-Battery chargers (also commonly known as DC-DC chargers) allow you to charge a leisure battery from your alternator whilst driving. They are installed in-line between the positive terminals of two batteries (one of which is connected to an alternator, typically a starter battery) and offer several benefits when compared with traditional split charge systems that utilise a Voltage Sensitive Relays. In a traditional split charge system with a VSR will only achieve around an 80% charge state. VSRs simply allow charge to pass directly from the alternator...
